Product advantages
➣Ideal for Excimer LaserApplication
➣High Transmission at 180nm to 8um
➣Custom Size Available
| Material | CaF2 |
| Dimension Tolerance | +0.0/-0.2mm |
| Thickness Tolerance | ±0.2mm |
| Clear Aperture | >90% |
| Parallelism | < 3 arc minutes |
| Surface Quality | 80/50 |
| Wavefront Distortion | <λ per 25mm@633nm |
| Chamfer | Protected <0.5mm @ 45° |
| Coating | None, per your request |
| Standard | |||
| Part No. | Material | ø(mm) | T(mm) |
| CAWD10T3 | CaF2 | 10.0 | 3.0 |
| CAWD12.7T3 | CaF2 | 12.7 | 3.0 |
| CAWD15T3 | CaF2 | 15.0 | 3.0 |
| CAWD20T3 | CaF2 | 20.0 | 3.0 |
| CAWD25.4T3 | CaF2 | 25.4 | 3.0 |
| CAWD30T3 | CaF2 | 30.0 | 3.0 |
| CAWD38.1T3 | CaF2 | 38.1 | 3.0 |
| CAWD50.8T6.35 | CaF2 | 50.8 | 6.35 |
| High Precision | |||
| Part No. | Material | ø(mm) | T(mm) |
| CAWD10T5 | CaF2 | 10.0 | 5.0 |
| CAWD12.7T5 | CaF2 | 12.7 | 5.0 |
| CAWD15T5 | CaF2 | 15.0 | 5.0 |
| CAWD20T5 | CaF2 | 20.0 | 5.0 |
| CAWD25.4T6.35 | CaF2 | 25.4 | 6.35 |
| CAWD30T6.35 | CaF2 | 30.0 | 6.35 |
| CAWD38.1T6.35 | CaF2 | 38.1 | 6.35 |
| CAWD50.8T10 | CaF2 | 50.8 | 10.0 |
