| Material | BK7 or UV Fused Silica |
| Design wavelength | BK7: 632.8nm, n=1.515@632.8nm UV Fused Silica: 355nm, n=1.476@355nm |
| Dimension tolerance | +0/-0.2mm |
| Thickness | 3mm on the thinnest edge |
| Surface quality | 60/40 |
| Clear aperure | >90% |
| Flatness | <λ/4@632.8nm |
| Wedge angle tolerance | < 3 arc min |
| Deviation angle | 1°-10° |
| Coating | No, avaliable |
| Part Number | Material | Dimension (mm) | T (mm) | θ (°) | Deflection (°) | Design Wavelength (nm) |
| WED25-1-FS | UVFS | 25.4 | 3 | 2.1 | 1 | 355 |
| WED25-2-FS | UVFS | 25.4 | 3 | 4.18 | 2 | 355 |
| WED25-4-FS | UVFS | 25.4 | 3 | 8.28 | 4 | 355 |
| WED25-6-FS | UVFS | 25.4 | 3 | 12.42 | 6 | 355 |
| WED25-1 | BK7 | 25.4 | 3 | 1.95 | 1 | 632.8 |
| WED25-2 | BK7 | 25.4 | 3 | 3.88 | 2 | 632.8 |
| WED25-4 | BK7 | 25.4 | 3 | 7.68 | 4 | 632.8 |
| WED25-6 | BK7 | 25.4 | 3 | 11.35 | 6 | 632.8 |
