Product advantages
➣Brewster angle incident at all surfaces yields greater than 98% transmission efficiency
➣Rejected beams available for beam splitting/beam combining applications or safe dumping
➣No anti-reflection coatings needed, suit for high power conditions
| Material | Calcite, YVO 4 |
| Wavelength Range | Calcite:350～2300 nm, YVO4:500～4000 nm |
| Extinction Ratio | <5x10-5 |
| Surface Quality | 20/10 scratch and dig |
| Beam Deviation | < 3 arc minutes |
| Wavefront Distortion | λ /4@633nm |
| Damage Threshold | >1000 MW/cm2 |
| Coating | No coating, Tp>98% @ 1064nm, Typical |
| Mount | Black Anodized Aluminium |
| 1. Calcite Brewster Polarizer | |||||
| Part No. | Wavelength Range | Extinction Ratio | C.A. φa (mm) | O.D. φd (mm) | L (mm) |
| PBR3005 | 350～2300nm | <5x10-5 | 5 | 15 | 18 |
| PBR3010 | 10 | 25.4 | 34 | ||
| 3. Yvo4 Glan Laser Polarizer | |||||
| Part No. | Wavelength Range | Extinction Ratio | C.A. φa (mm) | O.D. φd (mm) | L (mm) |
| PBR5005 | 500-4000nm | <5x10-6 | 5 | 18 | 21 |
| PBR5010 | 10 | 32 | 40 | ||
