Product advantages
➣High Extinction Ratio for Both Transmitted & Reflected Channels
➣Good Wavefront Distortion for Both Transmitted & Reflected Channels
| Material | BK7 |
| Dimension Tolerance | ±0.2mm |
| Surface Quality | 60/40scratch and dig |
| Clear Aperture | >90% |
| Transmissted Wavefront Distortion | λ/8@632.8nm per 10mm |
| Reflected Wavefront Distortion | λ/8@632.8nm per 10mm |
| Beam Deviation | <3arc minutes |
| Extinction Ratio | Tp/Ts>1000:1, Rs/Rp>200:1 |
| Principal Transmittance | Tp>97% |
| Principal Reflectance | Rs>99.5% |
| Coating | Polarization beamsplitter coating on hypotenuse face AR coating on all input and output faces |
| Damage Threshold | >500mJ/cm2, 20ns, 20Hz, @1064nm |
| Part Number | Material | Dimension (mm) | Thickness (mm) | Tp/Ts | Rs/Rp | Wavelength |
| PBST1212-633 | BK7 | 12.7*12.7 | 12.7 | >1000:1 | >200:1 | 633 |
| PBST2525-633 | BK7 | 25.4*25.4 | 25.4 | >1000:1 | >200:1 | 633 |
| PBST1212-780 | BK7 | 12.7*12.7 | 12.7 | >1000:1 | >200:1 | 780 |
| PBST2525-780 | BK7 | 25.4*25.4 | 25.4 | >1000:1 | >200:1 | 780 |
| PBST1212-1064 | BK7 | 12.7*12.7 | 12.7 | >1000:1 | >200:1 | 1064 |
| PBST2525-1064 | BK7 | 25.4*25.4 | 25.4 | >1000:1 | >200:1 | 1064 |
