Product advantages
➣Widest Field Angle
➣Cemented, Suitable for low power application
➣High Polarization Purity
| Material: | a-BBO, Calcite |
| Wavelength Range: | a-BBO: 200～3500 nm, Calcite: 350～2300 nm |
| Extinction Ratio: | a-BBO:<5x10-6 Calcite:<5x10-5 |
| Surface Quality: | 10/20 |
| Parellelism: | <1 arc Min |
| Beam Deviation: | < 3 arc minutes |
| Wavefornt Distortion: | λ /4@633nm |
| Wavefornt Distortion: | >200 MW/cm2 |
| Coating: | Single MgF2 |
| Mount: | Black Anodized Aluminium |
| 1.Calcite Glan Thompson Polarizer(350-2300nm) | ||||||
| Part No. | L/CA | Extinction Ratio | Angular Field | C.A. φa (mm) | O.D. φd (mm) | L (mm) |
| PGM2106 | 2.5 | <5x10-6 | ＞14～16° | 6 | 15 | 22 |
| PGM2108 | 8 | 25.4 | 28 | |||
| PGM2110 | 10 | 25.4 | 33 | |||
| PGM2112 | 12.7 | 25.4 | 39 | |||
| PGM2115 | 15 | 30 | 45.5 | |||
| PGM2206 | 3 | <5x10-6 | ＞25～28° | 6 | 15 | 26 |
| PGM2208 | 8 | 25.4 | 32 | |||
| PGM2210 | 10 | 25.4 | 38 | |||
| PGM2212 | 12.7 | 25.4 | 46 | |||
| PGM2215 | 15 | 30 | 53 | |||
| 2. a-BBO Glan Thompson Polarizer (200-1100nm) | ||||||
| Part No. | L/CA | Extinction Ratio | Angular Field | C.A. φa (mm) | O.D. φd (mm) | L (mm) |
| PGM1006 | 1.6 | <5x10-6 | >15° | 6 | 15 | 22 |
| PGM1008 | 8 | 25.4 | 28 | |||
| PGM1010 | 10 | 25.4 | 33 | |||
| PGM1012 | 12.7 | 25.4 | 39 | |||
| PGM1015 | 15 | 30 | 45.5 | |||
