| Dimensional Tolerance | ±0.1mm |
| Angle Tolerance | ±0.5deg |
| Surface Quality | 20/10 Scratch and Dig |
| Clear Aperture | >90% |
| Surface Flatness | <λ/8@633nm |
| Wavefront Distortion | <λ/4@633nm |
| Parallelism | <20 arc seconds |
| Perpendicularity | <5 arc minutes |
| Coating | Per your request |
| Part Number | Material | Dimension (mm) | Length (mm) | Cut | End Faces | Side Faces |
| BBO3320 | BBO | 3*3 | 20 | Z-cut | AR/AR@1064nm | Au Electrodes |
| BBO4420 | BBO | 4*4 | 20 | Z-cut | AR/AR@1064nm | Au Electrodes |
| BBO6620 | BBO | 6*6 | 20 | Z-cut | AR/AR@1064nm | Au Electrodes |
| BBO8820 | BBO | 8*8 | 20 | Z-cut | AR/AR@1064nm | Au Electrodes |
| BBO101020 | BBO | 10*10 | 20 | Z-cut | AR/AR@1064nm | Au Electrodes |
